RA VS Reaper Trigger Mods in RA Vecta 2…..Bad Result

SS trigger Mods in RA Vecta 2

It is a common question with Rob Allen Guns, why do they not use a stainless trigger?  I had the same question and after a few emails I caught up with Rob Allen to discuss. Surprisingly RA has experimented with of all kinds of trigger materials but landed on their newest grey version, a Kevlar composite.  It turns out the geometry of the RA mech lends itself to adhesive wear which happens on two metal parts that are subjected to high load low speed movement ie metal trigger to metal seer, this can be seen by remaining knurling.

The Constant:

A tradition unmodified handgun will have and average trigger somewhere between 5-7 lbs, yes some guns have lighter pull but this is an average.  The RA Kevlar trigger pull comes in at approximately 1.7kg or about 3.75 lbs.  The mechanism was fail tested after 17,000 shots and failed at 734lbs.  Fail testing consists of pulling the spear until the seer over rotates or another part of the mech fails releasing the spear.

The Untested Copy

Now days is you walk into a spearfishing  store you will notice that there are two guns that look alike, one the RA Tuna or Snapper series and the copy aka the JBL Reaper, one version of the JBL offering a stainless trigger. Now the spearfishing world is flooded with originals and copies, JBL copied an older Vecta mech including its flaws.

Pictured below #1 is the RA Vecta Mech from about 10 years ago, the Vecta has been modified over 10 times since. The second picture #2 is of the “copy” Reaper mech with metal trigger.

RA_Vecta_old



JBL_Metal



So it’s a copy, who cares and how do you know if the JBL is not better? The two triggers were subjected to a trigger load cycle test and the results were pretty revealing.



The Test

JBL Reaper Metal Trigger Results

Starting Trigger Pull: 3.8kg or 8.36lbs

50 shots: 6kg or 13.2lbs of pull

150 shots: 4.2-44kg around 9.24lbs of pull

200 shots later mech pulled to failure at 350 kg or 770 lbs, actually pretty good!

What caused the increase:

Trigger_test_JBL

As you can see by the results and pic, as the mech got used the metal seer and trigger started to rub therefore the trigger pull ramped up from the knurling.  After continued use the trigger pull went down, the only thing we can assume is the trigger would “polish” itself then start to knurl again. The ending trigger pull of 9.24 lbs is rather very high and very hard to pull.

Mech_Failure

The Aftermarket Trigger:

There are a few companies that have decided to sell aftermarket stainless steel triggers.  Most of them are very well done, so Rob decided to test one.



Starting : 2 kg then drops to 1.8kg with first 20 shots

After 40 shots: Trigger pull starts to ramp up

70 shots: pull is 4.72 kg or 10.38lbs

80 shots : 5.23kg or 11.6lbs

170 shots: trigger works its way to 6.07kg or an amazing 13.3 lbs

Stainless-trigger (002)



Stainless does work in many other mechs, but not in RA or its copies.  If you are noticing an increased trigger pull give your trigger an inspection and look for wear! More trigger tests on the horizon so stay tuned.

For Questions please feel free to reach out to us at : UltimateSpearfishingMedia@gmail.com
